    JINGLIN GG800 Horizontal Wrapping Machine Steel& Copper Overlap Scope 10%-90% Conveying Speed 10m-20m/Min

    Ask Lasest Price
    Brand Name : JLPACK
    Model Number : GG800
    Certification : ISO9001,CE
    Payment Terms : T/T
    Supply Ability : 200 sets/Year
    Delivery Time : Stand alone 1 week,the packing line 150 days
    • Product Details
    • Company Profile

    JINGLIN GG800 Horizontal Wrapping Machine Steel& Copper Overlap Scope 10%-90% Conveying Speed 10m-20m/Min

    JINGLIN GG800 Horizontal Wrapping Machine Steel& Copper Overlap scope 10%-90% Conveying speed 10m-20m/min


    Automatic Industrial Use Board Packing Steel& Copper Machine Wood Door Packing Machine


    Packing machine application:

    This packing line takes compound paper as the main packing material,applied for coil picking,auto packing,strapping stacking&etc of slit steel coils,makes the object well packed and strapping stacked,convenient for storage and transportation.


    The horizontal steel pipe wrapping machine is specialized for wrapping horizontal wood panels, wood door, batten board and other horizontal objects.


    Packing machine installation:

    The machine shall be mounted on flat & hard ground, where the ground load should be more than 1ton/m2.

    Photocell sensors are adopted for fixing the packing position.


    Packing machine installation basic operation:

    • Hoisting the pipe bundles onto the front conveyor line and ready to be wrapped, hoist the packed pipes away from the back convey line after package finished. The next wrapping process should begin after the back line cleared.
    • The wrapping material is tied, fixed and cut by manual.

    Packing machine installation main features:


    1. PLC programmable control.
    2. Wrapping position reset.
    3. Both automatic and semi-auto working mode for different choice.
    4. Photocell sensors are adopted for fixing the packing position.
    5. Indicator alarms automatically when trouble occurs.
    6. The turning ring is controlled by converter.
    7. Overlap rate of the wrapping material can be adjusted according to needs.
    8. Soft stop &soft start functions.
    9. Protective fence ensure safe operation.
    10. Packing material tension could be adjusted.
    11. Separate control panel makes operation & maintenance easily.
    12. Pressing down device and supportive rollers for fix the packaging position.
    13. Double-ring & double-rub wheel system make the wrapping more safe, stable & energetic.
    14. Automatic material feed & cutting system can be equipped for human operation.
    15. Material size are width:≤250mm,Max OD:400mm and the ID:55mm.
    16. Packing material are compound paper tape/knit tape/anti-rust tape/waterproof tape and LLDPE stretch film.
    17. The machine can be custom designed according to specific object size.

    MAIN PARAMETERS:

    ItemsGG800
    Height of the product≤800mm
    Weight≤2T
    Pipe lengthNot limited
    Conveyor length1000-6000mm(can be customized)
    Conveying speedAbout 10m-20m/min
    Rotating speedAbout 70r/min
    Conveyor heightApprox. 1000mm
    Overlap scopeAbout 10%-90%
    Power outputAbout 2.4kw
    Power voltage380V/ 3phase/50Hz
    Material

    Compound paper tape/knit tape/anti-rust tape/waterproof tape

    stretch film

    Material size

    width:≤250mm

    Max OD:400mm

    ID:55mm


    Note: the datas are only for reference, the machine can be custom designed according to specific object size.
