80r/Min High Efficient Aluminum Coil Wrapping Machine Easy Loading ID 508mm 4.0KW

    Buy cheap 80r/Min High Efficient Aluminum Coil Wrapping Machine Easy Loading ID 508mm 4.0KW from wholesalers

    Buy cheap 80r/Min High Efficient Aluminum Coil Wrapping Machine Easy Loading ID 508mm 4.0KW from wholesalers
    • Buy cheap 80r/Min High Efficient Aluminum Coil Wrapping Machine Easy Loading ID 508mm 4.0KW from wholesalers

    80r/Min High Efficient Aluminum Coil Wrapping Machine Easy Loading ID 508mm 4.0KW

    Ask Lasest Price
    Brand Name : jlpack
    Model Number : GD300
    Certification : ISO9001,CE
    Payment Terms : T/T
    Supply Ability : 200 sets/Year
    Delivery Time : Stand-alone 1 week ,the packing line 150days
    • Product Details
    • Company Profile

    80r/Min High Efficient Aluminum Coil Wrapping Machine Easy Loading ID 508mm 4.0KW

    80r/Min High Efficient Aluminum Coil Wrapping Machine Easy Loading ID 508mm 4.0KW



    80r/Min High Efficient Aluminum Coil Wrapping Machine Easy Loading ID 508mm 4.0KW​ application

    The Aluminum Coil Wrapping Machine is developed for packing different ring-shaped products including steel coils, aluminum coils, copper coils, wire coils, cable coils, pipe coils, tyres&etc by stretch film, paper or other packing material available. Easy operation and convenient maintenance. It greatly save the labor force and improve the work efficiency from the traditional manual packing.

    80r/Min High Efficient Aluminum Coil Wrapping Machine Easy Loading ID 508mm 4.0KW​ features

    1. The wrapping unit is moveable, safe&convenient for coil.
    2. Automatic control by PLC program.
    3. Standard modular design of the metal coil wrapping machine, stable performance, convenient maintenance.
    4. Solid whole casting structure for turning ring.
    5. Height of the wrapping ring adjustable for metal coils with different OD.
    6. The wrapping tape is cut automatically by the cutter.
    7. The indicator lights will alarm automatically when error happens.
    8. The rollers are wrapped by PU to protect the products effectively.
    9. Various kinds of packing material can be choose according to needs.
    10. HMI touch can be optioned for more smart operation.

    80r/Min High Efficient Aluminum Coil Wrapping Machine Easy Loading ID 508mm 4.0KW parameters

    ModelGD300
    TypeWrapper moveable
    Coil OD700mm-1500mm
    Coil ID508mm/610mm
    Coil width20mm-300mm
    Coil weight50kg-2000Kg
    Roller speed5-8m/min
    Ring speed80r/min
    Air supply6-8kgf/cm2
    Power outputAbout 4.0KW

    Note: the datas are only for reference, the machine can be custom designed according to specific object size.
