    Horizontal Steel Coil Wrapping Line / Auto Packing Line 60-500mm Width With Stacking System

    Ask Lasest Price
    Brand Name : jlpack
    Model Number : Customized
    Certification : ISO9001,CE
    Payment Terms : T/T
    Supply Ability : 200 sets/Year
    Delivery Time : Stand-alone 1 week ,the packing line 150days
    • Product Details
    • Company Profile

    Horizontal Steel Coil Wrapping Line / Auto Packing Line 60-500mm Width With Stacking System

    Horizontal Steel Coil Wrapping Line / Auto Packing Line 60-500mm Width with Stacking System

    Product application:

    This packing line take compound paper as main packing material,apply coil picking, auto packing, stacking&etc for slit steel coils, makes the object well packed and stacked, convenient for storage and transportation.


    Basic composition:

    The fully auto machinery is composed of coil loading system,wrapping machine, stacking system, electrical cabinet and guardrails.

    The machines can be assembly to get your packaging goal...

    We offer the best metal coil packaging solution which ensure your maximum packaging production and save your labor cost.

    And it providing a safety operation process for your staff.


    Techincal parameters(for reference):

    OD: 800mm~1500mm

    ID: 508-610mm

    Width: 60mm~500mm

    Weight: ≤ 5T

    Wrapping material: LLDPE stretch film/compound paper

    wrapping overlap: 30%~70% adjustable

    Wrapping material size: film roll width 90mm, roll OD 500mm,roll ID 76mm


    The Fuction of the machines:

    Coil Turnstile: For connecting with coil car for loading the slit coil.

    Coil car: For moving the coil from packaging loading and unloading.

    Coil down ender: For picking the slit coil from turnstile and changing coil from vertical to horizontal and moving to conveyor.

    Coil strapping machine: For coil strapping by PET/PE/steel belt.

    Coil wrapping machine: For coil eye cross wrapping with different packing material.

    Coil Stacking machine: For moving and and storage the packed coil on pallet.
