    VCI Paper Bearing Packing Machine Automactic Roller 1.5kw GW300 With Conveyor

    Ask Lasest Price
    Brand Name : jlpack
    Model Number : ZC300
    Certification : ISO9001,CE
    Payment Terms : T/T
    Supply Ability : 200 sets/Year
    Delivery Time : Stand-alone 1 week ,the packing line 150days
    • Product Details
    • Company Profile

    VCI Paper Bearing Packing Machine Automactic Roller 1.5kw GW300 With Conveyor

    VCI Paper Automactic Roller Bearing Packaging Machiney 1.5kw GW300 With Conveyor​


    VCI paper automatic roller bearing packaging machinery with conveyor​ application


    ZZ series bearing packing machine is widely used for various bearing packing.The packed object is well decorated and has good effect of rust-proof,dust-proof,water-proof,anti-wear and anti-damage.


    VCI paper automatic roller bearing packaging machinery with conveyor​ parameters:


    ModeZC100ZC200ZC300ZC400
    Machine TypeHorizontalHorizontalHorizontalHorizontal
    Object width≤100mm≤200mm≤300mm≤400mm
    Object ID≥150mm≥250mm≥400mm≥400mm
    Object OD≤500mm≤700mm≤1300mm≤2000mm
    Object weight≤100kg≤300kg≤500kg≤1000kg
    Ring speed10-100r/min10-100r/min10-100r/min10-100r/min
    Roller speed1-3m/min1-3m/min1-3m/min1-3m/min
    Packing material

    Stretch film/VCI film,etc

    Width: 50-60mm; core ID: 50mm; OD: 100-200mm

    Stretch film/VCI film,etc

    Width: 50-60mm; core ID: 50mm; OD: 100-200mm

    Stretch film/VCI film,etc

    Width: 50-60mm; core ID: 50mm; OD: 100-200mm

    Stretch film/VCI film,etc

    Width: 50-60mm; core ID: 50mm; OD: 100-200mm

    PE film/knit tape/compound paper tape/crepe paper,etc

    Width:50-60mm, core ID:55mm,

    OD: 100-500mm

    PE film/knit tape/compound paper tape/crepe paper,etc

    Width:50-60mm, core ID:55mm,OD: 100-500mm

    PE film/knit tape/compound paper tape/crepe paper,etc

    Width:50-60mm, core ID:55mm,OD: 100-500mm

    PE film/knit tape/compound paper tape/crepe paper,etc

    Width:50-60mm, core ID:55mm,OD: 100-500mm

    OutputAppr. 1.5kwAppr. 1.5kwAppr. 1.5kwAppr. 1.5kw
    Supply voltage220V/380V, 50HZ/60HZ220V/380V, 50HZ/60HZ220V/380V, 50HZ/60HZ220V/380V, 50HZ/60HZ
    Air supply6~8kgf/cm26~8kgf/cm26~8kgf/cm26~8kgf/cm2
    Automatic mechanical handOptionalOptionalOptionalOptional

    Note: the datas are only for reference, the machine can be custom designed according to specific object size.


    VCI paper automatic roller bearing packaging machinery with conveyor​ main features:

    1. Horizontal structure with motorized conveyors for efficient packing.

    2. Flexible wrapping table specially designed for turning of bearings.

    3. PLC and HMI for automatic operation.

    4. The tension and overlapping degree of wrapping material can be adjusted.

    5. Photo sensors for automatic coil positioning.

    6. Different packing material can be chose.

    7. Packaging tension is adjustable by special breaker.

    8. Independent control cabinet easy for operation and maintenance.

    9. Automatic material feeding and cutting is available.

    10. Safe guardrails for turning part ensure safe operation.
