    Industrial Profile Wrapping Machine 20m/Min Conveying Speed With Independent Operating Station

    Ask Lasest Price
    Brand Name : jlpack
    Model Number : GG700
    Certification : ISO9001,CE
    Payment Terms : T/T
    Supply Ability : 200 sets/Year
    Delivery Time : Stand alone 1 week,the packing line 150 days
    • Product Details
    • Company Profile

    Industrial Profile Wrapping Machine 20m/Min Conveying Speed With Independent Operating Station


    Industrial Profile Wrapping Machine 20m/min Conveying speed with Independent operating station


    Mchine application:


    The machine is specialized for wrapping horizontal steel tube,wood panels, wood door, batten board and other horizontal objects.

    The wrapped package is well-protected & sealed & looks more tidy.

    We offers a wide variety of opinions to meet your specific requirements.Each applications is evaluated to provide the reght solution to your needs.


    MAIN PARAMETERS


    ItemsGG700
    Height of the product≤700mm
    Pipe lengthNot limited
    Conveyor length1000-6000mm(can be customized)
    Conveying speedAbout 8-12m/min
    Rotating speedAbout 70r/min
    Conveyor heightApprox. 900mm
    Overlap scopeAbout 10%-90%
    Power outputAbout 6Kw
    Power voltage380V/ 3phase/50Hz
    Material

    Compound paper tape/knit tape/anti-rust tape/waterproof tape

    stretch film

    Material size

    width:≤250mm

    Max OD:300mm

    ID:55mm


    Note: the datas are only for reference, the machine can be custom designed according to specific object size.


    Main features:

    1. Double-ring & double-rub wheel system make the wrapping more safe, stable & energetic.
    2. PLC programmable control.
    3. Both automatic and semi-auto working mode for different choice.
    4. Photocell sensors are adopted for fixing the packing position.
    5. Overlap rate of the wrapping material can be adjusted according to needs.
    6. Soft stop &soft start functions.
    7. Packing material tension could be adjusted.
    8. Separate control panel makes operation & maintenance easily.
    9. Pressing down device and supportive rollers for fix the packaging position.
    10. Wrapping position reset.
    11. Protective fence ensure safe operation.
    12. Automatic material feed & cutting system can be equipped for human operation.

    Advantages of Horizontal Wrapping Machine :


    • Protect the surface of the product

    • Improve production efficiency

    • Dust proof

    • Moisture proof

    • High efficiency

    • Heavy duty appearance


    Industrial Profile Wrapping Machine 20m/Min Conveying Speed With Independent Operating Station
