    GG600 Stretch Film Packing Machine Steel Pipe Wrapping Conveying Speed 10m-20m/Min

    Ask Lasest Price
    Brand Name : jlpack
    Model Number : GG600
    Certification : ISO9001,CE
    Payment Terms : T/T
    Supply Ability : 200 sets/Year
    Delivery Time : Stand alone 1 week,the packing line 150 days
    • Product Details
    • Company Profile

    GG600 Stretch Film Packing Machine Steel Pipe Wrapping Conveying Speed 10m-20m/Min

    GG600 Stretch Film Packing Machine Steel Pipe Wrapping Conveying speed 10m-20m/min


    Alias:High Quality Stretch Film Packing Machine Film Wrapping Machine


    Machine application:

    The horizontal steel pipe wrapping machine is specialized for wrapping horizontal wood panels, wood door, batten board and other horizontal objects. The wrapped product is well-protected ,with good effect of rust-proof,dust-proof,water-proof,anti-wear and anti-damage.


    Basic operation:

    • Hoisting the pipe bundles onto the front conveyor line and ready to be wrapped, hoist the packed pipes away from the back convey line after package finished.
    • The next wrapping process should begin after the back line cleared.
    • The wrapping material is tied, fixed and cut by manual.

    Main features:

    1. Double-ring & double-rub wheel system make the wrapping more safe, stable & energetic.
    2. PLC programmable control.
    3. Automatic alarming when trouble occurs.
    4. The turning ring is controlled by converter.
    5. Overlap rate of the wrapping material can be adjusted according to needs.
    6. Soft stop &soft start functions.
    7. Packing material tension could be adjusted.
    8. Separate control panel makes operation & maintenance easily.
    9. Pressing down device and supportive rollers for fix the packaging position.
    10. Wrapping position reset.
    11. Protective fence ensure safe operation.
    12. Automatic material feed & cutting system can be equipped for human operation.

    MAIN PARAMETERS:


    ItemsGG600
    Height of the product≤600mm
    Pipe lengthNot limited
    Conveyor length1000-6000mm (can be customized)
    Conveying speedAbout 8-12m/min
    Rotating speedAbout 70r/min
    Conveyor heightApprox 800mm
    Overlap scopeAbout 10%-90%
    Power outputAbout 4kw
    Power voltage380V / 3phase / 50Hz
    Material

    Compound paper tape/knit tape/anti-rust tape/waterproof tape

    stretch film

    Material size

    width:≤250mm

    Max OD:250mm

    ID:55mm


    Note: the datas are only for reference, the machine can be custom designed according to specific object size.
