    Horizontal Steel Wire Packing Machine Online Operation 70r/Min Coil Packaging Machine

    Ask Lasest Price
    Brand Name : jlpack
    Model Number : GW300
    Certification : ISO9001,CE
    Price : USD
    Payment Terms : T/T
    Supply Ability : 200 sets/Year
    Delivery Time : Stand-alone 1 week ,the packing line 150days
    • Product Details
    • Company Profile

    Horizontal Steel Wire Packing Machine Online Operation 70r/Min Coil Packaging Machine

    Horizontal Steel Wire Packing Machine Online Operation 70r/min Coil Packaging Machine


    Application:

    The wire and cable wrapping machine is mainly applied for packing various coiled wire or cable products which is in horizontal state, to make the product well-protected and sealed from water, dust and crushes. The machine replaces the traditional manual packing and can greatly improve the packing efficiency and save labor force.


    Basic feature:

    1. Excellent collections with high quality brands adopted for main electrical parts.

    2. The turning speed of the ring and carrier rollers is adjustable by converter.

    3. The overlap of packing tape can be adjusted by inverters.

    4. The wrapping tape tension can be adjusted.

    5. Press roller and side rollers adopted to prevent the project from shaking in packing.

    6. The wrapping material can be cut automatically.

    7. The supporting rollers are wrapped by polyurethane for protection.

    8. Indicator alarms automatically when trouble occurs.

    9. Friction between wheel and ring is adjustable.

    10. Soft start and soft stop ensure safe operation.

    11. Simply structure, easy for operation and maintenance.


    Machine​ parameters


    Wrapping typeGW200-NGW200-WGW300-NGW300-W
    Coil OD600-1200mm600-1200mm600-1200mm600-1200mm
    Coil ID≥400mm≥400mm≥400mm≥400mm
    Coil width≤200mm≤200mm≤300mm≤300mm
    Coil weight≤300KG≤500KG≤300KG≤500KG
    Cutting typeManual cuttingAuto cuttingManual cuttingAuto cutting
    Ring speedAppr.70r/minAppr.80r/minAppr.70r/minAppr.80r/min
    Packing materialknit tape, compound paper, stretch film, non-woven fabrics,etcknit tape, compound paper etcknit tape, compound paper,stretch film, non-woven fabrics,etc

    knit tape,

    compound paper, etc

    Material width100-120mm80-100mm100-120mm80-100mm
    Material OD200mm450mm200mm450mm
    Material ID55mm55mm55mm55mm
    Power outputAbout 1.5KWAbout 2.2KWAbout 1.5KWAbout 2.2KW
    Power supplyAC/380VAC/380VAC/380VAC/380V
    Air supplyWithoutWith(6-8kgf/cm2)WithoutWith(6-8kgf/cm2)
    Pushing-out systemOptionalOptionalOptionalOptional
    Circular labeling systemOptionalOptionalOptionalOptional
    Synchronous wrapping systemOptionalOptionalOptionalOptional

    Note: the datas are only for reference, the machine can be custom designed according to specific object size.
